High-performance automatic edge banding machine with pre-milling for efficient, precise, and high-quality edge finishing in commercial woodworking operations.
Integrated pre-milling unit ensures optimal panel preparation for flawless edge adhesion.
Fully automatic operation increases throughput with a consistent feeding speed of 13m/min.
Comprehensive functions include gluing, end cutting, fine trimming, scraping, and polishing.
Handles edge banding materials (PVC, ABS, Veneer) from 0.4mm to 3mm thickness.
Processes panels from 10mm to 60mm thickness and a minimum width of 50mm.
Advanced features include board preheating, non-stick glue pot, and precision six-edge trimming knives.
Pneumatic controls and integrated dust collection enhance usability and maintain a clean workspace.
Edging Thickness: 0.4-3mm
Panel Thickness: 10-60mm
Panel Feeding Speed: 13 m/min
Required Air Pressure: 0.7 Mpa
Total Power Consumption: 6.23 kW
Overall Dimensions (L*W*H): 3700 * 750 * 1500 mm
